TD52P

Resolution	75,000
Resolution (Certified)	10,000
Battery Life	20 Hours with Rechargeable Battery
Item Number:	30424078

Request a Quote ADD TO QUOTE LIST

View All TD52P Models

Overview
Specs
Accessories
Documents

Overview

The OHAUS next generation Defender 5000 Series multifunctional indicator is ideal for use in conjunction with bench and floor scales for a multitude of applications including production, packaging, inventory and shipping. Built durably and equipped with advanced features such as maximum configurability print output, GMP/GLP data output, library/user management and multiple connectivity options - the Defender 5000 Series is designed to handle demanding industrial and commercial applications.

Applications

Weighing, Parts Counting, Percent Weighing, Check Weighing, Dynamic Weighing (Display Hold), Filling

Display

Backlit Liquid Crystal Display (LCD), 256 x 80 pixels

Operation

Internal power supply with power cord (included) or rechargeable battery (sold separately as an accessory)

Communication

Easy access communication ports including RS232 and Micro SD slot (included), second RS232/RS485/USB device, Ethernet and WiFi/Bluetooth, Discrete I/O and Analog Output (sold separately as accessories); GLP/GMP data output with real-time clock

Construction

ABS plastic housing

Design Features

Check weighing symbols with selectable operation and audible signal settings, menu lock switch, multiple operating languages, selectable environmental and auto-print settings, stability indicator, overload/underload indicators, selectable adjust contrast settings, auto-dim, auto-off, auto tare, screensaver

Specifications

Resolution	75,000
Resolution (Certified)	10,000
Battery Life	20 Hours with Rechargeable Battery
Outputs	4 - 20mA;2 In/4 Out digital I/O
Second Scale Input	Not Applicable
Protection Rating	Not Applicable
Communication	Ethernet (Available as an Accessory);2nd RS232/RS485/USB (available as an accessory);RS232 (Included);USB (Available as an Accessory);WiFi/Bluetooth (available as an accessory)
Dimensions	10.4 in x 7.6 in x 3 in (265 mm x 192 mm x 75 mm) (LxHxW)
Display	Dot matrix LCD with white LED backlight
Legal for Trade	NTEP Certified;Measurement Canada Approved
Net Weight	3 lb (1.5 kg)
Power	Rechargeable Battery (Not Included);AC Power (Included)
Protection Rating	Not Applicable
Tare Range	To capacity by subtraction
Units of Measurement	Metric Tons;Gram;Kilogram;Pound;Tonne;Custom;Ounce;Pound:Ounce
Working Environment	14°F – 104°F, 85%RH, non-condensing (-10°C – 40°C, 85%RH, non-condensing)
